The Zeta125S pipe lasers make your work more convenient and safer. Thanks to the unique vertical alignment, which can be easily performed with the remote control and a laser receiver, there is no need to climb down into the trench. The Zeta125G, with the green laser, provides four times higher visibility, superior leveling accuracy and allows greater working distances. These features help you achieve the best visibility in nearly any working condition at a distance up to 200 m (650 feet). You can be confident that you will achieve maximum efficiency with this pipe laser.
Zeta125
SPECIFICATION
- Zeta125 / Zeta125 US / Zeta125G / Zeta125G US / Zeta125S / Zeta125SG
- Laser beam
Red / Red / Green / Red / Green
- Laser class
2 / 3R / 2M / 3R / 3R / 3R
- Cross axis leveling
Manual / Manual / Manual / Manual / Automatic (6°) / Automatic (6°)
- Vertical level
No / No / No / No / Yes / Yes
- Autotarget system
No / No / No / No / Yes / Yes
- Manual alignment
No / No / No / No / Yes / Yes
- Self-leveling range
-15% to +45%
- Grade range
-10% to +40%
- Protection
IP68
- Power supply
Rechargeable lithium ion battery pack 110/230V AC converter (charge and run simultaneously); 12V power cord
- Battery life
40h Li-Ion battery
- Thread mounting
5/8”
- Operating temperature
+50°C to -20°C (122°F to -4°F)
- Size and weight
305 (12”) x 105 (4.1”) x 113 mm (4.4”); 2.07 kg
- Operating range
< 200 m (656’)
- Detection angle
20° (12 m / 40’ @30 m / 100’)
- Rotation speed
1250 rpm
REMOTE CONTROL
- Operating range
190 m (600’) front through the pipe; 7.6 m (25’) from rear
- Batteries
3 AA alkaline
- Dimensions
119 x 60 x 30 mm (4.7” x 2.35” x 1.2”)
