The t100xf signal transmitter is compact, robust and easy to use. It has four frequencies designed to trace buried utilities over long distances when used in conjunction with the EZiCAT xf-Series cable locators.
EZiTEX t100xf
SPECIFICATION
- Frequency
8kHz, 33kHz, 640Hz, 512Hz
- Protection
IP67 Case lid closed
IP65 Case lid open
- Connection Power Output
Up to 3W max
- Induction Power Output
Up to 3W max
- Power Output Control
4 power level setting
- Batteries
4 x D alkaline (IEC LR20) supplied
- Battery operating time
15 h intermittent use (at 68°F)
- Weight & dimensions
5.5lbs - 5.24in (H) x 8.11in (D) x 9.84in (W)
