a6100

SPECIFICATION

• Technical

• 24 MP, APS-C sensor

  20 mm lens

  nadir configuration

• Payload weight (incl. mount)

• 550 g (0.73 lb)

• Lowest possible GSD

• 1.2 cm/px

  0.47 in/px

• Maximum coverage at lowest GSD*

• Up to 120 ha (300 ac) at 61 m (200 ft) flight altitude

• Maximum coverage at 120 m (400 ft)*

• Up to 240 ha (600 ac) at 2.4 cm (0.9 in) GSD

• Horizontal absolute accuracy (RMS) with PPK (w/o GCPs)

• Down to 2 cm (0.8 in)

• Vertical absolute accuracy (RMS) with PPK (w/o GCPs)

• Down to 4 cm (1.6 in)

• Sensor type

• APS-C

• Sensor size x

• 23.5 mm (0.93 in)

• Sensor size y

• 15.6 mm (0.61 in)

• Mega pixel

• 24.2

• Shutter type

• Focal plane

• Pixel in x

• 6000

• Pixel in y

• 4000

• Focal length of lens

• 20 mm (0.79 in)

• Focal length (35mm equivalent)

• 29.8 mm (1.17 in)

• Vertical field of view

• 42.6°

• Horizontal field of view

• 60.9°

• Minimal trigger time

• 1.0 s

• Minimal trigger distance

• 16 m (52 ft)

GSD overview

• GSD at 120 m flight altitude

• 2.4 cm/px (0.93 in/px)

• Flight altitude

• 120 m (400 ft)

• Maximum frontal overlap

• 83%

• Maximum coverage

• 240 ha (600 ac)

• Lowest possible GSD

• 1.2 cm/px (0.47 in/px)

• Flight altitude

• 61 m (200 ft)

• Maximum frontal overlap

• 67%

• Maximum coverage

• 120 ha (300 ac)

• 2.0 cm/px GSD

• 2 cm/px (0.79 in/px)

• Flight altitude

• 102 m (330 ft)

• Maximum frontal overlap

• 87%

• Maximum coverage

• 205 ha (500 ac)
