The GeoMax ZAL200 Series are dependable and durable tools, specifically designed for construction professionals. With three different types of magnification, a new ergonomic and solid-built design, and full range of accessories and services, the GeoMax ZAL200 auto levels provide great quality at affordable value.
ZAL200
SPECIFICATION
ACCURACY
- ZAL220
2.5 mm
TELESCOPE
- Image
Erect
- Magnification
20 x
- Field of view
< 2.1 m at 100 m
- Shortest target distance from instrument axis
< 1.0 m
ACCURACY
- ZAL224
2.0 mm
TELESCOPE
- Image
Erect
- Magnification
24 x
- Field of view
< 2.1 m at 100 m
- Shortest target distance from instrument axis
< 1.0 m
ACCURACY
- ZAL232
2.0 mm
TELESCOPE
- Image
Erect
- Magnification
32 x
- Field of view
< 2.1 m at 100 m
- Shortest target distance from instrument axis
< 1.0 m
COMPENSATOR
- Working range
± 15’
- Setting accuracy
0.5’’
DISTANCE MEASUREMENT
- Multiplication factor
100
- Additive constant
0
CIRCULAR LEVEL
- Sensitivity
8’/2 mm
CIRCLE
- Graduation
360°
- Graduation interval
1°
ADAPTATION
- Central fixing screw
5/8”
ENVIRONMENTAL
- Operating temperature
-20°C to +50°C (-4°F to +122°F)
- Protection
IP56
