DJI Mini Series

SPECIFICATION

• Takeoff Weight

• 248 g

• Dimensions

• Folded (without propellers): 148×90×62 mm (L×W×H)

  Unfolded (with propellers): 251×362×72 mm (L×W×H)

• Max Ascent Speed

• 5 m/s

• Max Descent Speed

• 3.5 m/s

• Max Horizontal Speed (at sea level, no wind)

• 16 m/s

• Max Takeoff Altitude

• With Intelligent Flight Battery: 4000 m

  With Intelligent Flight Battery Plus: 3000 m

• Max Flight Time

• 38 minutes (with Intelligent Flight Battery)

  51 minutes (with Intelligent Flight Battery Plus)

• Max Hovering Time

• 33 minutes (with Intelligent Flight Battery)

  44 minutes (with Intelligent Flight Battery Plus)

• Max Flight Distance

• 18 km (with Intelligent Flight Battery and measured while flying at 43.2 kph in windless conditions)

  25 km (with Intelligent Flight Battery Plus and measured while flying at 43.2 kph in windless conditions)

• Max Wind Speed Resistance

• 10.7 m/s (Level 5)

• Max Tilt Angle

• 40°

• Operating Temperature

• -10° to 40° C (14° to 104° F)

• Global Navigation Satellite System

• GPS + GLONASS + Galileo

Hovering Accuracy Range

• Vertical:

• ±0.1 m (with vision positioning)

  ±0.5 m (with GNSS positioning)

• Horizontal:

• ±0.3 m (with vision positioning)

  ±1.5 m (with GNSS positioning)

• Internal Storage

• N/A

Camera

• Image Sensor

• 1/1.3-inch CMOS

  Effective Pixels：48MP

• Lens

• FOV: 82.1°

  Format Equivalent: 24 mm

  Aperture: f/1.7

  Focus: 1 m to ∞

• ISO Range

• Video:100-3200

  Photo: 100-3200

• Shutter Speed

• Electronic Shutter: 2-1/8000 s

• Max Image Size

• 8064×6048

• Still Photography Modes

• Single Shot: 12 MP

  48 MP: 48 MP

  Timed: 12 MP

  JPEG: 2/3/5/7/10/15/20/30/60 s

  JPEG + RAW: 5/7/10/15/20/30/60 s

• Photo Format

• JPEG/DNG (RAW)

• Video Resolution

• 4K: 3840×2160@24/25/30 fps

  2.7K: 2720×1530@24/25/30/48/50/60 fps

  FHD: 1920×1080@24/25/30/48/50/60 fps

  HDR: Recording with the 24/25/30fps frame rate supports outputting HDR images.

• Video Format

• MP4 (H.264)

• Max Video Bitrate

• 100 Mbps

• Supported File System

• FAT32 (≤ 32 GB)

  exFAT (> 32 GB)

• Color Mode

• Normal

• Digital Zoom

• 4K: 2×

  2.7K: 3×

  FHD: 4×

• QuickShots Modes

• Dronie, Helix, Rocket, Circle, and Boomerang

Gimbal

• Stabilization

• 3-axis mechanical gimbal (tilt, roll, and pan)

• Mechanical Range

• Tilt: -135° to 80°

  Roll: -135° to 45°

  Pan: -30° to 30°

• Controllable Range

• Tilt: -90° to 60°

  Roll: -90° or 0°

• Max Control Speed (tilt)

• 100°/s

• Angular Vibration Range

• ±0.01°

Sensing

• Sensing Type

• Downward vision system

• Downward

• Precise Hovering Range: 0.5-10 m

• Operating Environment

• Downward: Diffuse reflective surfaces with a clear pattern and reflectivity > 20% (such as walls, trees, or people)

  Adequate lighting (lux > 15, normal indoor lighting conditions)

Video Transmission

• Video Transmission System

• DJI O2

• Live View Quality

• Remote Controller: 720p/30fps

• Operating Frequency

• 2.400-2.4835 GHz

  5.725-5.850 GHz

• Transmission Power (EIRP)

• 2.400-2.4835 GHz:< 26 dBm (FCC) / < 20 dBm (CE/SRRC/MIC)

• Max Transmission Distance (free of interference)

• 5.725-5.850 GHz:< 26 dBm (FCC/SRRC) / < 14 dBm (CE)

• Max Transmission Distance (with interference)

• Max Download Speed

• 5.5 MB/s (with DJI RC-N1 Remote Controller)

  5.5 MB/s (with DJI RC)

  Wi-Fi 5: 25 MB/s

• Lowest Latency

• Approx. 200 ms

• Antenna

• 2 antennas, 1T2R

Battery

• Capacity

• Intelligent Flight Battery: 2453 mAh

  Intelligent Flight Battery Plus*: 3850 mAh

• Weight

• Intelligent Flight Battery: Approx. 80.5 g

  Intelligent Flight Battery Plus*: Approx. 121 g

• Nominal Voltage

• 7.38 V

• Max Charging Voltage

• 8.5 V

• Type

• Li-ion

• Energy

• Intelligent Flight Battery: 18.1 Wh

  Intelligent Flight Battery Plus*: 28.4 Wh

• Charging Temperature

• 5° to 40° C (41° to 104° F)

Charging Time

• Intelligent Flight Battery:

• 64 minutes (with the DJI 30W USB-C Charger and the battery mounted to the aircraft)

  56 minutes (with the DJI 30W USB-C Charger and the battery inserted into the Two-Way Charging Hub)

• Intelligent Flight Battery Plus:

• 101 minutes (with the DJI 30W USB-C Charger and the battery mounted to the aircraft)

  78 minutes (with the DJI 30W USB-C Charger and the battery inserted into the Two-Way Charging Hub)
