The DJI Matrice 350 RTK drone is a high-end unmanned aerial vehicle that boasts powerful capabilities and advanced features, making it a top choice for professionals in various industries. This drone is designed for use in commercial applications such as industrial inspections, search and rescue missions, mapping, and more. Equipped with advanced sensors and a high-precision RTK positioning system, the DJI Matrice 350 RTK drone can fly for up to 55 minutes and cover a range of up to 15 kilometers. This enables it to conduct long-range missions with ease while delivering high-quality data and imagery.. Furthermore, the DJI Matrice 350 RTK drone comes with an array of customizable payloads and accessories, allowing users to tailor it to their specific needs. These include a high-resolution camera, a thermal imaging camera, and a spotlight, among others. The Matrice 350 RTK is the latest commercial drone platform that takes inspiration from modern aviation systems. Offering up to 55 minutes of flight time, advanced AI capabilities, 6 Directional Sensing & Positioning and more, the M350 RTK sets a whole new standard by combining intelligence with high-performance and unrivaled reliability.
Matrice 350 RTK
SPECIFICATION
- Dimensions
Unfolded, propellers excluded, 810×670×430 mm (L×W×H)
Folded, propellers included, 430×420×430 mm (L×W×H)
- Diagonal Wheelbase
895 mm
- Weight (with single downward gimbal)
Approx. 3.6 kg (without batteries)
Approx. 6.3 kg (with two TB60 batteries)
- Single Gimbal Damper’s Max Payload
960g
- Max Takeoff Weight
9.2 kg
- Operating Frequency
2.4000-2.4835 GHz
5.150-5.250 GHz (CE: 5.170-5.250 GHz)
5.725-5.850 GHz
- EIRP
2.4000-2.4835 GHz:
< 33 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)
5.150-5.250 GHz (CE: 5.170-5.250 GHz):
< 23 dBm (CE)
5.725-5.850 GHz:
< 33 dBm (FCC/SRRC)
< 14 dBm (CE)
- Hovering Accuracy (P-mode with GPS)
Vertical:
±0.1 m (Vision System enabled)
±0.5 m (GPS enabled)
±0.1 m (RTK enabled)
Horizontal:
±0.3 m (Vision System enabled)
±1.5 m (GPS enabled)
±0.1 m (RTK enabled)
- RTK Positioning Accuracy
When RTK enabled and fixed:
1 cm+1 ppm (Horizontal)
1.5 cm + 1 ppm (Vertical)
- Max Angular Velocity
Pitch: 300°/s
Yaw: 100°/s
- Max Pitch Angle
30°
- Max Ascent Speed
mode: 6 m/s
- Max Descent Speed
5 m/s
- Max Speed
S mode: 23 m/s
P mode：17 m/s
- Service Ceiling Above Sea Level
5000 m (with 2110 propellers, takeoff weight ≤ 7 kg) / 7000 m (with 2195 propellers, takeoff weight ≤ 7 kg)
- Max Wind Resistance
12 m/s
- Max Flight Time
55 min
- Supported DJI Gimbals
Zenmuse XT2/XT S/Z30/H20/H20T/DJI P1/DJI L1
- Supported Gimbal Configurations
Single Downward Gimbal, Dual Downward Gimbals, Single Upward Gimbal, Upward and Downward Gimbals, Triple Gimbals
- Ingress Protection Rating
IP55
- GNSS
GPS+GLONASS+BeiDou+Galileo
- Operating Temperature
-20°C to 50°C (-4°F to 122° F)
Remote Controller
- Operating Frequency
2.4000-2.4835 GHz
5.725-5.850 GHz
- Max Transmitting Distance (unobstructed, free of interference)
NCC/FCC: 15 km
CE/MIC: 8 km
SRRC: 8 km
- EIRP
2.4000-2.4835 GHz:
29.5 dBm (FCC) 18.5dBm (CE)
18.5 dBm (SRRC); 18.5dBm (MIC)
- External battery
Name: WB37 Intelligent Battery
Capacity: 4920 mAh
Voltage: 7.6V
Type: LiPo
Energy: 37.39Wh
Charging time (using BS60 Intelligent Battery Station): 70 minutes (15°C to 45°C); 130 minutes (0°C to 15°C)
Intelligent Flight Battery
- Model
TB65
- Capacity
5880 mAh
- Voltage
44.76 V
- Type
Li-ion
- Energy
263.2 Wh
- Weight
Approx. 1.35 kg
- Operating Temperature
-20° to 50° C (-4° to 122° F)
- Ideal Storage Temperature
22° to 30° C (71.6° to 86° F)
- Charging Temperature
-20° to 40° C (-4° to 104° F)
- Charging Time
With a 220V power supply, it takes approximately 60 minutes to fully charge two TB65 Intelligent Flight Batteries and approximately 30 minutes to charge them from 20% to 90%.
With a 110V power supply, it takes approximately 70 minutes to fully charge two TB65 Intelligent Flight Batteries and approximately 40 minutes to charge them from 20% to 90%.
Vision System
- Obstacle Sensing Range
Forward/Backward/Left/Right: 0.7-40m
Upward/Downward: 0.6-30m
- FOV
Forward/Backward/Downward: 65° (H), 50° (V)
Left/Right/Upward: 75°(H), 60°(V)
- Operating Environment
Surfaces with clear patterns and adequate lighting (> 15 lux)
Infrared Sensing System
- Obstacle Sensing Range
0.1-8m
- FOV
30° (±15°)
- Operating Environment
Large, diffuse and reflective obstacles (reflectivity >10%)
FPV Camera
- Resolution
1080p
- FOV
142°
- Frame rate
30 fps
Intelligent Flight Battery
- Name
TB60
- Capacity
5935 mAh
- Voltage
52.8 V
- Battery Type
LiPo 12S
- Energy
274 Wh
- Net Weight
Approx. 1.35 kg
- Operating Temperature
-4°F to 122°F (-20°C to 50°C)
- Ideal storage temperature
71.6°F to 86°F (22°C to 30°C)
- Charging Temperature
-4°F to 104°F (-20°C to 40°C)
(When the temperature is lower than 5°C, the self-heating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)
- Charging time
Using BS60 Intelligent Battery Station:
220V input: 60 minutes (fully charging two TB60 batteries), 30 minutes (charging two TB60 batteries from 20% to 90%)
110V input: 70 minutes (fully charging two TB60 batteries), 40 minutes (charging two TB60 batteries from 20% to 90%)
Intelligent Battery Station
- Dimensions
580×358×254 mm (L×W×H)
- Net Weight
Approx. 8.98 kg
- Maximum Capacity
Eight TB65 Intelligent Flight Batteries
Four WB37 Intelligent Batteries
- Input Voltage
100-120 VAC, 50-60 Hz
220-240 VAC, 50-60 Hz
- Max. Input Power
1070W
- Output Power
100-120 V: 750 W
220-240 V: 992 W
- Operating Temperature
-20° to 40° C (-4° to 104° F)
