DJI Mavic 3 Enterprise Series

SPECIFICATION

• Weight

• DJI Mavic 3E: 915 g

  DJI Mavic 3T: 920 g

• Takeoff Weight

• DJI Mavic 3E: 1,050 g

  DJI Mavic 3T: 1,050 g

• Dimensions

• Folded (without propellers): 221×96.3×90.3 mm (L×W×H)

  Unfolded (without propellers): 347.5×283×107.7 mm (L×W×H)

• Diagonal Distance

• 380.1 mm

• Max Ascent Speed

• 6 m/s (Normal Mode)

  8 m/s (Sport Mode)

• Max Descent Speed

• 6 m/s

• Max Flight Speed (at sea level, no wind)

• 15 m/s (Normal Mode)

  Forward: 21 m/s, Side: 20 m/s, Backward: 19 m/s (Sport Mode)

• Max Wind Speed Resistance

• 12 m/s

• Max Takeoff Altitude

• 6000 m (without payload)

• Max Flight Time (no wind)

• 45 minutes

• Max Hover Time (no wind)

• 38 minutes

• Max Flight Distance

• 32 km

• Max Pitch Angle

• 30° (Normal Mode)

  35° (Sport Mode)

• Operating Temperature

• -10° to 40° C (14° to 104° F)

• Global Navigation Satellite System

• GPS+Galileo+BeiDou+GLONASS (GLONASS is supported only when the RTK module is enabled)

• Internal Storage

• N/A

Wide Camera

• Sensor

• DJI Mavic 3E: 4/3 CMOS, Effective pixels: 20 MP

  DJI Mavic 3T: 1/2-inch CMOS, Effective pixels: 48 MP

• Lens

• DJI Mavic 3E:

  FOV: 84°

  Format Equivalent: 24 mm

  Aperture: f/2.8-f/11

  Focus: 1 m to ∞

  DJI Mavic 3T:

  FOV: 84°

  Format Equivalent: 24 mm

  Aperture: f/2.8

  Focus: 1 m to ∞

• ISO Range

• DJI Mavic 3E: 100-6400

  DJI Mavic 3T: 100-25600

• Shutter Speed

• DJI Mavic 3E:

  Electronic Shutter: 8-1/8000 s

  Mechanical Shutter: 8-1/2000 s

  DJI Mavic 3T:

  Electronic Shutter: 8-1/8000 s

• Max Image Size

• DJI Mavic 3E: 5280×3956

  DJI Mavic 3T: 8000×6000

• Still Photography Modes

• DJI Mavic 3E:

  Single: 20 MP

  Timed: 20 MP

  JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s

  JPEG+RAW: 3/5/7/10/15/20/30/60 s

  Smart Low-light Shooting: 20 MP

  Panorama: 20 MP (raw image)

  DJI Mavic 3T:

  Single: 12 MP/48 MP

  Timed: 12 MP/48 MP

  JPEG: 2/3/5/7/10/15/20/30/60 s

  Panorama: 12 MP (raw image); 100 MP (stitched image)

• Video Resolution

• H.264

  4K: 3840×2160@30fps

  FHD: 1920×1080@30fps

• Bitrate

• DJI Mavic 3E:

  4K: 130 Mbps

  FHD: 70 Mbps

  DJI Mavic 3T:

  4K: 85 Mbps

  FHD: 30 Mbps

• Supported File Formats

• exFAT

• Photo Format

• DJI Mavic 3E: JPEG/DNG (RAW)

  DJI Mavic 3T: JPEG

• Video Format

• MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)

• Supported File System

• exFAT

Gimbal

• Stabilization

• 3-axis mechanical gimbal (tilt, roll, pan)

• Mechanical Range

• DJI Mavic 3E:

  Tilt: -135° to 100°

  Roll: -45° to 45°

  Pan: -27° to 27°

  DJI Mavic 3T:

  Tilt: -135° to 45°

  Roll: -45° to 45°

  Pan: -27° to 27°

• Controllable Range

• Tilt: -90° to 35°

  Pan: Not controllable

• Max Control Speed (tilt)

• 100°/s

• Angular Vibration Range

• ±0.007°

Sensing

• Sensing Type

• Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft

• Forward

• Measurement Range: 0.5-20 m

  Detection Range: 0.5-200 m

  Effective Sensing Speed: Flight Speed ≤15 m/s

  FOV: Horizontal 90°, Vertical 103°

• Backward

• Measurement Range: 0.5-16 m

  Effective Sensing Speed: Flight Speed ≤ 12 m/s

  FOV: Horizontal 90°, Vertical 103°

• Lateral

• Measurement Range: 0.5-25 m

  Effective Sensing Speed: Flight Speed ≤ 15 m/s

  FOV: Horizontal 90°, Vertical 85°

• Upward

• Measurement Range: 0.2-10 m

  Effective Sensing Speed: Flight Speed ≤ 6 m/s

  FOV: Front and Back 100°, Left and Right 90°

• Downward

• Measurement Range: 0.3-18 m

  Effective Sensing Speed: Flight Speed ≤ 6 m/s

  FOV: Front and Back 130°, Left and Right 160°

• Operating Environment

• Forward, Backward, Left, Right, and Upward

  surfaces with discernible patterns and adequate lighting (lux >15)

  Downward:surfaces with discernible patterns, diffuse reflectivity >20% (e.g. walls, trees, people), and adequate lighting (lux >15)

Thermal Camera

• Thermal Imager

• Uncooled VOx Microbolometer

• Pixel Pitch

• 12 μm

• Frame Rate

• 30 Hz

• Lens

• DFOV: 61°

  Format Equivalent: 40 mm

  Aperture: f/1.0

  Focus: 5 m to ∞

• Noise Equivalent Temperature Difference (NETD)

• ≤50 mK@F1.0

• Temperature Measurement Method

• Spot Meter, Area Measurement

• Temperature Measurement Range

• -20° to 150° C (-4° to 302° F, High Gain Mode)

  0° to 500° C (32° to 932° F, Low Gain Mode)

• Palette

• White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2

• Photo Format

• JPEG (8-bit)

  R-JPEG (16-bit)

• Video Resolution

• 640×512@30fps

• Bitrate

• 6 Mbps

• Video Format

• MP4 (MPEG-4 AVC/H.264)

• Still Photography Modes

• DJI Mavic 3T:

  Single: 640×512

  Timed: 640×512

  JPEG: 2/3/5/7/10/15/20/30/60 s

• Digital Zoom

• 28x

• Infrared Wavelength

• 8-14 μm

• Infrared Temperature Measurement Accuracy

• ±2° C or ±2% (using the larger value)

Battery

• Capacity

• 5000 mAh

• Weight

• 335.5 g

• Nominal Voltage

• 15.4 V

• Max Charging Voltage

• 17.6 V

• Type

• Li-ion 4S

• Energy

• 77 Wh

• Charging Temperature

• 5° to 40° C (41° to 104° F)

• Charging Time

• Approx. 96 minutes

Charger

• Input

• 100-240 V (AC Power), 50-60 Hz, 2.5 A

• Output Power

• 100 W

• Output

• Max. 100 W (total) When both ports are used, the maximum output power of each interface is 82 W, and the charger will dynamically allocate the output power of the two ports according to the load power.

Battery Charging Hub

• Input

• USB-C: 5-20 V, 5.0 A

• Output

• Battery Port: 12-17.6 V, 8.0 A

• Rated Power

• 100 W

• Charging Type

• Three batteries charged in sequence

• Compatibility
