Highlights:

The GeoMax Zoom75 Series Robotic Total Station is packed with modern features to meet your surveying needs while remaining surprisingly affordable. This survey device is a smart choice for either construction professionals or surveying novices.

Clear

SKU: N/A Category:
Description

The GeoMax Zoom75 Series Robotic Total Station is packed with modern features to meet your surveying needs while remaining surprisingly affordable. This survey device is a smart choice for either construction professionals or surveying novices.

Zoom75

SPECIFICATION

  • Accuracy
  • 1”, 2”, 3”, 5”

  • Display resolution
  • 0.1”

  • Method
  • Absolute, continuous, diametrical

  • Compensation
  • Quadruple axis

TELESCOPE

  • Type
  • accXXess

  • Magnification
  • 30x

  • NavLight™ Range
  • 5 m - 150 m

  • NavLight™ Accuracy
  • 5 cm at 100 m

DISTANCE MEASUREMENTS - PRISM

  • Range
  • 3500 m (std. prism) / 10,000 m

  • Accuracy
  • 1 mm + 1.5 ppm

  • Typ. time (fast/standard)
  • 0.8 / 2.4 sec

DISTANCE MEASUREMENTS - NON-PRISM

  • Range
  • 500 m / 1000 m

  • Accuracy
  • 2 mm + 2 ppm (< 500 m), 4 mm + 2 ppm (> 500 m)

  • Footprint
  • 8x 20 mm @ 50 m

INTERFACE

  • Keyboard
  • Two full alphanumeric

  • Display
  • Color & Touch, 5” WVGA 800 x 480 pixel with LED backlight

  • Date recording
  • Internal memory, 2 GB

  • Bluetooth
  • internal & long-range Bluetooth handle

  • Removable memory
  • SD card / USB stick

  • Ports
  • Serial, USB, USB mini, external power, WLAN

SOFTWARE

  • Operating System
  • Open Windows CE

  • Open for 3rd party SW
  • yes

  • Basic package
  • Fully flexible

  • Advanced package
  • Fully flexible

PHYSICAL SPECIFICATIONS

  • Weight
  • 5.0 - 5.3 kg w/o battery and tribrach

  • Operating temperature
  • -20 °C to 50 °C

  • Protection class
  • IP55

POWER SUPPLY

  • Type/Operating time
  • removable, up to 8 hours

PLUMMET

  • Type
  • Laser point, adjustable brightness

MOTORIZATION

  • Scout -360° Prism Search: Range
  • -

  • AiM - Prism fine aiming: Range / Accuracy
  • 1000 m at round prism / 1”

TRack -Prism following

  • Range
  • 800 m at round prism

  • Max. speed
  • 90 km/h at 100 m
