Reach RX

1,799.00

In Stock (VAT not included)
Highlights:

Reach RX uses Bluetooth allowing you to connect and start surveying in a few seconds. No settings to get wrong.

Category:
Description

Pocket-sized and lightweight receiver. Works with NTRIP corrections.

Reach RX

SPECIFICATION

  • Precision
  • H: 7 mm+1 ppm

    V: 14 mm+1 ppm

  • Convergence time
  • ~5 s typically

  • Signal tracked
  • GPS/QZSS L1C/A, L2C,

    GLONASS L1OF, L2OF,

    BeiDou B1I, B2I,

    Galileo E1-B/C, E5b

  • Number of channels
  • 184

  • Update rates
  • 5 Hz

CONNECTIVITY

  • Communication interface
  • Bluetooth 4.2

  • Ports
  • USB Type-C

  • Input data format
  • RTCM3

  • Input data protocol
  • NTRIP

  • Position output
  • NMEA

MECHANICAL

  • Dimensions
  • 172x51x51 mm

    (6.77x2.00x2.00 in)

  • Mount
  • 5/8”-11 UNC

  • Weight
  • 250 g (8.81 oz)

  • Ingress protection
  • IP68 (maximum depth of 1.5 meters up to 30 minutes)

  • Operating tº
  • -20 to + 65 °C

ELECTRICAL

  • Autonomy
  • Up to 16 hrs

  • Battery
  • Li-Ion 5200 mAh, 3.6 V, 18.72 Wh

  • Charging
  • USB Type-C, 5 V, 2 A

  • Certification
  • FCC, CE, IC
